ISM Series Managed Industrial Ethernet Switch
ISM Series Managed Industrial Ethernet Switch

Managed Industrial Ethernet Switches

The ISM series supports various network redundancy protocols, offering users a flexible choice for building complex industrial Ethernet communication systems. Whether in harsh production environments or industrial applications with strict requirements for reliability and availability, InHand Networks’ industrial Ethernet switches can meet your needs.

 / Managed Industrial Ethernet Switches

Stable and reliable, meeting the challenges of harsh industrial environments

  • Sturdy metal casing, fanless design
  • EMC/Protection Rating: Level 4/IP40
  • MTBF: 35 years
  • International Certifications: UL, CE, FCC
  • Redundant dual power inputs, Wide Temperature, Wide Voltage
High Protection Rating of ISM Managed Industrial Ethernet Switch
Advanced Ring Network of ISM Series Managed Industrial Ethernet Switch

Advanced ring network technology, protecting the core network

Supports STP, RSTP, and MSTP protocols, and for applications that require higher network redundancy, some models also support ERPS networking protocol

Supports multiple installation methods and network management approaches

  • Supports DIN-rail and rack mounting installation

  • Supports easy network management via web browser, serial port, RMON, and SNMP
Multiple installation methods and network management approaches of ISM Managed Industrial Ethernet Switch
Comprehensive network security performance of ISM Managed Industrial Ethernet Switch

Comprehensive network security performance

  • ACL policies, MAC address binding, VLAN
  • Supports QoS, IGMP Snooping, GMRP

Which Model is Right for You?

ModelISM5006DISM5010DISM5012DISM5020D
10/100/1000BaseT(X) Ports
(RJ45 connector)
48816
100/1000BaseSFP Ports2244
Backplane Bandwidth44 Gbps44 Gbps56 Gbps68 Gbps
MAC Table Size8 K8 K8 K16 K
Packet Buffer Size4 Mbits4 Mbits4 Mbits4 Mbits

Datasheet →Datasheet →Datasheet →

Buy Now →
Datasheet →
ModelISM5026UISM5310DISM7028U
10/100/1000BaseT(X) Ports
(RJ45 connector)
20/16
100/1000BaseSFP Ports224
PoE Ports
10/100/1000BaseT(X),
(RJ45connector)
/8/
Combo Ports
(10/100/1000BaseT(X) or 100/1000BaseSFP)
4/8
Backplane Bandwidth56 Gbps44 Gbps144 Gbps
MAC Table Size8 K8 K16 K
Packet Buffer Size4 Mbits4 Mbits1.5 Mbits
ISM8028UDatasheet →Datasheet →Datasheet →
