EC942
Lightweight
AI Edge Computer

Lightweight RK3568-based AI edge computer for industrial IoT, with a 2.0GHz quad-core ARM Cortex-A55, 4GB RAM, and 16GB eMMC for stable, efficient edge computing.

Request a Quote
Buy Now


Lightweight Industrial AI Edge Computer

AI Edge Computing Performance
RK3568 with NPU for lightweight AI inference and edge workloads.
Rich Industrial Interfaces
Supports Ethernet, serial, CAN, USB, and multiple industrial interfaces.
Stable Multi-Network Connectivity
Supports cellular, Ethernet, and Wi-Fi with link backup and dual SIM failover.
Industrial-Grade Security
Secure Boot, TPM 2.0, firewall, and VPN protect system and data security.
Edge Data Acquisition
Supports multi-protocol data acquisition and local preprocessing.
Cloud-Based Device Management
Enables remote access, batch device management, and container operations.
  • Core Technical Specifications
    Cellular Network 5G SA/NSA or LTE Cat4/Cat6 (model-dependent)
    Cloud Management DeviceLive, HTTP/HTTPS/SSH remote management
    CPU/GPU Quad-core [email protected] / Mali-G52 2EE
    Data Acquisition Modbus RTU/TCP, EtherNet/IP, OPC UA, DNP3.0, BACnet, CNC
    Dimensions (W × D × H) 47.3 × 162.7 × 148.3 mm
    Interfaces 2×GE, 2×RS-232/485/422, USB2.0, HDMI2.0, mSATA, MicroSD
    Network Features APN/VPDN, CHAP/PAP, ARP/Ethernet, static IP/DHCP
    Open Platform Yocto/Linux and Debian 10, Debian package manager
    Power Input DC 12~48V (8W)
    Protection Rating IP30
    RAM/Storage 4GB / 16GB eMMC
    Security (TPM2.0 Optional) Secure Boot, TPM2.0, firewall, VPN
  • Hardware Platform
    CPU Quad-core [email protected]
    FLASH 16GB eMMC
    GPU Mali-G52 2EE
    NPU RKNN AI acceleration engine
    RAM 4GB
  • Connectivity & Interfaces
    Buttons Pinhole reset button
    CAN (Optional) CAN2.0A/B
    Ethernet Ports 2×10/100/1000Mbps GE
    I/O Ports (Optional) 4×DI + 4×DO
    LED Indicators 4G/5G, Signal Strength (L1, L2, L3), SIM1, SIM2, User1, User2, PWR, STATUS, WARN, ERR
    Serial Ports 2×RS-232/485/422 (DB9)
    SIM Card Holders 2×MicroSIM
    TF Supports MicroSD cards up to 32GB (recommended maximum
    USB USB2.0 (2×Type-A + 1×Type-C)
  • Operating System
    File System Debian core root filesystem
    Operating System Yocto/Linux, Debian 10 (Kernel 4.19)
    Package Manager Debian package manager
  • Network Features
    Access Authentication APN, VPDN, CHAP/PAP
    LAN Protocols ARP, Ethernet
    Network Access 5G / LTE Cat4 / LTE Cat6 (model-dependent), Ethernet
    WAN Protocols static IP, DHCP
  • Security
    Secure Boot Supported
    Trust Zone Supported
  • Reliability
    Backup Mechanism Dual SIM backup
    Built-in Watchdog Embedded watchdog
    Dual SIM Switchover Supported
    Link Detection Multi-level link detection and auto-redial
  • Data Acquisition Protocols (DSA)
    Electricity Protocols DLT645-2007, IEC101/104, DNP3.0
    Industrial Protocols Modbus RTU Master/Slave, Modbus TCP Master/Slave, EtherNet/IP, ISO on TCP, OPC UA, Mitsubishi family, FINSUDP, HostLink, PPI
    Other Protocols BACnet, CNC
  • Network Management
    DeviceLive Cloud Supports cloud-based parameter configuration, container management, application and firmware management
    Log Functions Local/remote logs with power-off persistence
    Remote management DeviceLive / HTTP / HTTPS / SSH remote management
    Upgrade Method Local/remote firmware upgrade
Fetching resources...

Standard package*

  • EC942 AI Edge Computer *1
  • 4G Antenna *1
  • 5G Antenna *4
  • Wi-Fi Antenna *2
  • GNSS Antenna *1
  • Ethernet Cable *1
  • Optional accessories
  • Power Supply *1

* Standard package contents vary by standard order codes.

Contact us directly to learn more about our packaging options.

DeviceLive

IoT Device Management Platform

Device management, remote monitoring, edge app management, and remote maintenance to help industrial enterprises build intelligent edge networks.

Learn More

Related Cases

Preview

Safety Monitoring Solution for Vehicle Gas Cylinders

Safety Monitoring Solution for Vehicle Gas Cylinders Applications and Cases Key Takeaways…

Learn More →
See All Cases →

Frequently Asked Questions

What AI workloads is the EC942 designed for?

The EC942 is a Lite AI Edge Computer with a quad-core ARM Cortex-A55 @ 2.0 GHz CPU and a 1 TOPS NPU (RKNN). Designed for industrial IoT applications — lightweight edge AI inference and industrial data acquisition via the optional DSA service. OS options at ordering: IEOS (default — InHand’s edge runtime with web GUI, container management, and DeviceLive cloud integration) or Debian Linux ( -D suffix). Hardware variants: B is the entry-level config; H adds Wi-Fi, GPS, CAN, Bluetooth, and TPM. Cellular options span LTE Cat 4, 5G NR, regional EU/APAC, and no-cellular SKUs. For heavier vision analytics, step up to the EC3320 (6 TOPS) or EC5350/EC5550 (40 / 100 TOPS).

The EC942 is a Debian-based edge AI computer with 1× HDMI 2.0 + USB ports — three access methods are supported.

Direct (HDMI): Connect HDMI display + USB keyboard/mouse. Power on and log in with the System User credentials printed on the device nameplate. Use the Linux desktop directly.

Remote — SSH: Connect to the default ETH1 ( 192.168.3.100 ) or ETH2 ( 192.168.4.100 ) IP using an SSH client. Log in with the System User credentials from the nameplate. Note: root SSH login is disabled by default; use sudo -s after logging in as the system user.

Remote — IEOS web: Open https://192.168.4.100:9100 (HTTPS only, port 9100). Log in as username adm with the nameplate password.

IEOS (default, no OS suffix) is InHand’s edge operating system. It bundles the web GUI, cellular dialing, VPN, firewall, container management, and DeviceLive cloud integration as a pre-configured stack. Choose IEOS for fastest time-to-deploy and out-of-the-box integration with InHand’s cloud platform.

Debian Linux ( -D suffix) is a standard Debian distribution without InHand’s edge applications. Choose Debian for custom application stacks, third-party runtimes, or your own DevOps tooling — you take on cellular dialing and remote management yourself.

The EC942 uses InHand DeviceLive for cloud management. Registration is done in the DeviceLive portal — no configuration is needed on the device’s web GUI. Log in to your DeviceLive tenant, click Add Device, and enter the EC942’s serial number and credentials from the device label. Once the device has internet, it auto-connects to DeviceLive. From there, manage the fleet via remote container management and remote firmware/application management across distributed sites.

—
